Wireless Gas Detector
Your kitchen is safe?
would it happen gas leak?
Gas dectector can you a piece of mind.
1. Product List
- Wi-Fi Combustible Gas Detector x1
- Electromagnetic Valve/Manipulator 2P Terminal Adapter Cable x1
- Installation Adhesive Sticker x1
- Installation Screw Set x2
- Type-C + 5V/1A Power Supply x1
- User Manual x1
- Electromagnetic Valve/Manipulator (optional)
2. Specifications
Power Supply | Type-C + 5V/1A |
Operating Current | <200mA |
Applicable Gases | Methane (Natural Gas), Liquefied Petroleum Gas |
Operating Environment | Temperature: -10~55℃ Humidity: <95% RH (non-condensing) |
Sampling Method | Natural Diffusion |
Measurement Range | 0~100% LEL |
Alarm Set Concentration Value | 6% LEL |
Alarm Concentration Error | ±3% LEL |
Response Time | ≤30 seconds Automatic Recovery in Normal Environment |
High-Temperature Alarm Set Value | 57℃ |
Alarm Volume | ≥70dB (at 1 meter in front) |
Alarm Methods | Audible and Visual Alarm, Voice Prompt, Mobile Alarm Push Notification |
Alarm Linkage Output | Electromagnetic Valve: 12V Pulse Output Manipulator: 12V/300mA Output, lasts 15 seconds |
Warm-Up Time | 180 seconds |
Service Life | 5 years (under normal usage conditions) |
Wi-Fi | 2.4GHz, IEEE802.11b/g/n |
Installation Method | Wall-mounted |
Dimensions | 86x86x24.5mm |
3.Core Functions
- 1.77" TFT color display
- Voice prompts
- Perpetual calendar, real-time ambient temperature, and combustible gas display
- Combustible gas alarm
- High-temperature alarm (alarm threshold can be set)
- Green power indicator light, red alarm indicator light, yellow sensor fault indicator light, yellow life indicator light
- Test/Mute button
- Supports Chinese and English
- Alarm linkage with external shut-off devices like electromagnetic valves/manipulators
4.Romtely control device
- Cloud service provided by Tuya.
- Support for both smart configuration and compatible configuration Wi-Fi setup methods.
- Real-time display of combustible gas concentration and environmental temperature values.
- Push notifications for combustible gas alarm, high temperature alarm, self-check results, etc.
- Remote testing.
- Remote mute.
- High temperature alarm threshold setting.
- Language setting.
- Factory reset command.
3. Product Structure Diagram
3.1 Dimensions
Length x Width x Height: 86x86x35 (unit: mm)
3.2 Front View
3.3 Side View
3.4 Rear View
